Mobile HGV Brake Tester For Sale

Brake testing is a requirement in the UK for commercial vehicles to be checked on their braking system periodically every 4 – 12 weeks dependent on vehicle.

Mobile HGV Brake Tester For Sale
Mobile HGV Brake Tester For Sale
  • Mobile HGV Brake Tester For Sale
  • Mobile HGV Brake Tester For Sale
Mobile HGV Brake Tester For Sale
Mobile HGV Brake Tester For Sale

A commercial brake tester is a machine that checks the braking system on a commercial vehicle and then gives an overall result of either pass or fail dependent on the braking system meeting the criteria.

The criteria needed for a vehicle to pass on a brake tester is set out by the DVSA in the UK to ensure commercial vehicles on the UK roads are running safely. A brake tester uses the latest DVSA software to calculate percentages and to give the overall result.

A mobile brake tester does the same thing as a commercial brake tester. Mobile brake tester carries out a check on vehicles to ensure the braking system is up to Government DVSA standards, this is done by checking:

  • Service brake
  • Secondary brake
  • Park brake
  • Bind
  • Ovality
  • ULTAST dependent on vehicle

Mobile brake testers are still a relatively new product for the UK and unlike inground commercial brake testers, have the following benefits:

  • No civil works required
  • Moveable between depots and other testing locations
  • Suitable for uneven surfaces with self-levelling feet.

Everquip’s mobile brake tester, comes with the following technical specification as standard:



Max Axle Load: 20,000kgs
Minimum Testing Width: 800mm
Maximum Testing Width: 3,000mm
Gearbox and Motor: 15kw
Operation: Soft-start with duplex chain
Height: 196mm
Movement: 4 heavy duty wheels and winch

Get your quote today

Case Studies

phoenix-truck-trailer

Phoenix Truck and Trailer

Get in touch

Heavy Duty Gearbox and Motor

Heavy Duty Gearbox and Motor

The gearbox and motor are not only the most important but have the highest expenditure behind a commercial brake testing system. Our system includes 15kw motor and gearbox which run the duplex chain on the commercial brake tester which generates the speed for the rollers required to test the braking system.
PC Controlled & Tablet Operated

PC Controlled & Tablet Operated

The brake tester is PC controlled using the Latest DVSA software to calculate pass and fail percentages. The brake tester also comes with a tablet which is controlled in cab by the operator allowing an effective one-man test.
8 Weight Cells

8 Weight Cells

Unlike other commercial brake tester our system uses 8 dynamic weight cells to calculate axle loads of vehicles and to work with the DVSA software to calculate bind and pass / fail result. The 8 weight cells allow ultimate precision during the weighing process to ensure the most accurate results.
Bi-Directional

Bi-Directional

Allowing a vehicle to be tested in drive on or reverse on direction this allows a commercial brake tester to be used in even the smallest of spaces.
Soft-Start Operation

Soft-Start Operation

The Everquip commercial brake tester runs a soft start motor which enables the rollers to start up softly putting less pressure on the gearbox and motor.
Roller brake locking

Roller brake locking

Allowing you to drive the vehicle out of the brake tester safely first time, every time.
TUV Nord & CE Approved

TUV Nord & CE Approved

Quality control and reliability are essential when considering capital investment.
20,000kgs Axle Load

20,000kgs Axle Load

Choosing a brake tester with an axle load of 20,000kgs means you have the capability of testing most vehicles including; HGV’s, PSV’s, Busses, Coaches, Cranes and Heavy Duty Plant Equipment.
